Bike Varial 20" 1010 HS

Rekommenderad ålder: 15 + år

Storlek: 20" hjulbas 1010mm

Vikt: 7,4kg

Färg: Svart/Flourocerande gul

Jitsie tar innovation till nästa nivå med Jitsie Varial trialcykel. Tillverkning med högsta precition och kvalitet, minimalistisk design resulterar i en högpresterande cykel som gör det valet enkelt för alla förare.

Lättaste cykeln på marknaden i sin klass. Mycket prisvärd med tanke på kvalitet och vikt.

Frameset:
* frame: Jitsie Varial 1010mm HS
* fork: Jitsie Varial 370mm HS

Features frame:
* manufactured from aerospace 6061-T6 aluminium
* minimalistic design with focus on performance and durability
* 120mm high CNC machined head tube designed for semi-integrated headset
* 68mm wide bottom bracket shell for ISIS bottom bracket
* CNC machined integrated rear brake boaster for HS rim brakes distanced 100mm apart
* CNC machined horizontal dropouts distanced 116mm apart come supplied with steel snail cam bolts
* sandblasted and black anodized finish with Jitsie graphics
* frame comes supplied with lightweight silicon seat plug
* frame allows for the Jitsie aftermarket seat to be installed

Geometry:
* wheelbase: 1010mm
* chainstay length: 350mm
* bottom bracket height: 80mm
* headtube: 120mm
* headtube angle: 71.5°
(geometry based on Jitsie Varial fork 370mm and +45mm offset)

Wheels:
* hub front / rear: HS100 28h / HS116 32h
* rim front / rear: 20" 32mm 28h / 19" 48mm 32h
* spokes / nipples: inox 1.8mm / aluminium
* tyre front / rear: Reverz 20"x2.0 / Reverz 19"x2.6
* tubes: 20" light 0.9mm

Components:
* headset: semi-integrated 1 1/8"
* headset spacer: 5mm aluminium
* stem: 150mm 35°
* handlebar: 31.8mm 730x110mm
* grips: foam
* front brake: Magura HS33
* rear brake: Magura HS33

Drivetrain:
* bottom bracket: Isis 123mm
* cranks: 160mm
* freewheel: 108.9 18t
* protector: bash plate
* sprocket: steel 12t
* chain: KMC Z610HX
* chain tensioner: snail cams
